Labotemp Benchtop pH Meter LPM 102 delivers precise pH measurement for laboratory analysis, quality control, research, and routine testing of liquid samples. The benchtop system measures from −2.000 to 20.000 pH with selectable 0.01 and 0.001 pH resolution and accuracy of ±0.002 pH plus one digit. A high resolution 7 inch touch screen provides clear viewing and convenient operation, while automatic calibration and automatic temperature compensation support consistent pH measurement.
The system combines pH measurement with temperature monitoring and optional mV measurement when an appropriate ORP probe is used. It supports 1 to 5 point automatic pH calibration, timing data logging, parameter setup, and storage of up to 500 readings per parameter. The setup includes a refillable glass pH probe, stainless steel temperature probe, flexible probe holder, magnetic stirrer, standard pH buffer solutions, PC cable, and power adaptor, providing a complete benchtop arrangement for laboratory pH testing.
Why Choose Labotemp Benchtop pH Meter LPM 102?
✓ Precise pH Measurement: Provides a −2.000 to 20.000 pH range with 0.001 pH resolution and ±0.002 pH accuracy plus one digit.
✓ 7 Inch Touch Screen: High resolution touch screen with graphic and text based navigation provides convenient operation and clear measurement viewing.
✓ Intelligent Measurement Functions: Automatic calibration, automatic temperature compensation, timing data logging, and parameter setup support efficient laboratory testing.
| No. | Specification | Value |
|---|---|---|
| pH Measurement | ||
| 1 | Measurement Range(pH) | −2.000 to 20.000 pH |
| 2 | Resolution | 0.001 / 0.01 pH |
| 3 | Accuracy | ±0.002 pH ±1 digit |
| 4 | Calibration Points | 1 to 5 points, automatic |
| 5 | Temperature Compensation | Automatic |
| 6 | ATC Range | −10.0 to 135.0°C / 14.0 to 275.0°F |
| mV / ORP Measurement | ||
| 7 | Measurement Range(mV / ORP) | −1999.9 to +1999.9 mV |
| 8 | Resolution- | 0.1 / 1 mV |
| 9 | Accuracy- | ±0.03% FS ±1 digit |
| 10 | ORP Probe | Optional |
| Temperature Measurement | ||
| 11 | Measurement Range | −10.0 to 135.0°C / 14.0 to 275.0°F |
| 12 | Resolution. | 0.1°C |
| 13 | Accuracy. | ±0.2°C |
| Display and Data Management | ||
| 14 | Display | 7 inch high resolution TFT touch screen |
| 15 | Data Storage | 500 readings per parameter |
| 16 | Data Export | USB flash disk, PC, wireless printer |
| 17 | Printer | Optional |
| 18 | Data Logger | Timing data logger |
| 19 | Interface | Graphic and text based navigation |
| Construction and Power | ||
| 20 | Protection Class | IP54 |
| 21 | Power Supply | DC 12V |
| 22 | Probe Holder | Flexible probe holder |
| 23 | Magnetic Stirrer | Included |
| 24 | pH Probe | Glass refillable combination pH probe |
| 25 | Temperature Probe | Stainless steel temperature probe |
Chemical Laboratories: Suitable for routine pH and mV measurement during chemical analysis, sample preparation, and laboratory research.
Pharmaceutical Laboratories: Supports pH testing during formulation research, quality control, and laboratory analysis.
Food and Beverage Laboratories: Suitable for pH testing of liquid samples during quality control and product analysis.
Water Quality Testing: Supports pH and temperature measurement for laboratory based water analysis and quality monitoring.
Environmental Laboratories: Suitable for laboratory analysis of environmental liquid samples where pH measurement is required.
Research Laboratories: Supports controlled pH measurement during chemical, biological, and biochemical research.
Educational Laboratories: Suitable for teaching laboratories and practical experiments involving pH, temperature, and mV measurement.
Quality Control Laboratories: Supports routine measurement and quality control workflows requiring repeatable pH analysis.
