Specifications
|
Temperature Range :
Standard 0°C to -10°C
Temperature Range |
Standard 0°C to -10°C |
|
Foamed Urethane Thickness (mm) :
100
Foamed Urethane Thickness (mm) |
100 |
|
Thickness of Stainless Steel :
Outer: 1.0 mm Body Tray: 1.0 mm Inner: 0.6 mm
Thickness of Stainless Steel |
Outer: 1.0 mm Body Tray: 1.0 mm Inner: 0.6 mm |
|
Refrigerant :
R404A
Refrigerant |
R404A |
|
Temperature Accuracy :
0.1°C
Temperature Accuracy |
0.1°C |
|
Compressor Place :
Back of the freezer
Compressor Place |
Back of the freezer |
|
Working Temperature :
10–38°C
Working Temperature |
10–38°C |
|
Compressor :
Germany Secop / Chinese compressor (optional)
Compressor |
Germany Secop / Chinese compressor (optional) |
|
Compressor Number :
1 independent control of each chamber
Compressor Number |
1 independent control of each chamber |
|
Number of Body Tray :
1
Number of Body Tray |
1 |
|
Door count :
1
Door count |
1 |
|
Body Tray Load Capacity :
200 kg
Body Tray Load Capacity |
200 kg |
|
Body Tray Size (mm) :
1940×580
Body Tray Size (mm) |
1940×580 |
|
External Size (mm) :
2280×800×600
External Size (mm) |
2280×800×600 |
|
Inner Room Size (mm) :
1950×630×440
Inner Room Size (mm) |
1950×630×440 |
|
Chamber Height (mm) :
440
Chamber Height (mm) |
440 |
|
Rate of Work :
218W/1.2A
Rate of Work |
218W/1.2A |
|
Voltage :
220V/50Hz
Voltage |
220V/50Hz |
|
Material :
Stainless steel 304
Material |
Stainless steel 304 |
|
Packing Size (mm) :
2320×850×760
Packing Size (mm) |
2320×850×760 |
|
Package :
Plywood
Package |
Plywood |
|
Net Weight :
120 kg
Net Weight |
120 kg |
|
Gross Weight :
150 kg
Gross Weight |
150 kg |
Features
-
ISO & CE Certified
➤ ISO & CE Certified
-
304 stainless steel anti-corrosion body
➤ 304 stainless steel anti-corrosion body
-
All-in-one design with easy installation
➤ All-in-one design with easy installation
-
8 cm foamed urethane insulation for fast cooling
➤ 8 cm foamed urethane insulation for fast cooling
-
LED digital temperature control
➤ LED digital temperature control
-
Independent SECOP compressor system
➤ Independent SECOP compressor system
-
Stainless steel trays (200 kg) with silent rollers
➤ Stainless steel trays (200 kg) with silent rollers
-
Side-open safety door with lock
➤ Side-open safety door with lock
-
7-type alarm protection
➤ 7-type alarm protection
-
Removable trays with smooth sliding
➤ Removable trays with smooth sliding
-
5-inch universal wheels with nylon rollers
➤ 5-inch universal wheels with nylon rollers
Applications
-
Used for reliable preservation and storage of human bodies in hospitals, mortuaries, funeral homes, and forensic facilities
➤ Used for reliable preservation and storage of human bodies in hospitals, mortuaries, funeral homes, and forensic facilities
- ISO & CE Certified
- 304 stainless steel anti-corrosion body
- All-in-one design with easy installation
- 8 cm foamed urethane insulation for fast cooling
- LED digital temperature control
- Independent SECOP compressor system
- Stainless steel trays (200 kg) with silent rollers
- Side-open safety door with lock
- 7-type alarm protection
- Removable trays with smooth sliding
- 5-inch universal wheels with nylon rollers
Used for reliable preservation and storage of human bodies in hospitals, mortuaries, funeral homes, and forensic facilities.
