Small Freeze Dryer LFD-302

Name: Small Freeze Dryer LFD-302
Brand: Labotemp
SKU: LFD-302
Price: 15530.00 USD
Availability: InStock
Rating: 4.8 (891 reviews)

Labotemp Small Freeze Dryer LFD-302 provides flexible freeze-drying for laboratories requiring both chamber and external flask lyophilization. This compact benchtop freeze dryer features four external drying ports, making it suitable for processing liquid samples, biological materials, enzymes, plant extracts, pharmaceuticals, and laboratory chemicals with minimal handling. Equipped with an -88°C cold trap, 40 L chamber capacity, 0.1 m² freeze-drying area, and ≤0.1 Pa ultimate vacuum, the system delivers stable drying conditions while preserving sample structure and biological activity. The transparent chamber door enables continuous observation throughout the drying cycle.

Designed for efficient laboratory workflows, the LFD-302 incorporates a 7-inch touchscreen PLC controller with programmable lyophilization methods, real-time monitoring of vacuum and temperature, historical data storage, and USB data export for process traceability. Automatic cold trap defrosting, intelligent diagnostics, vacuum protection, and audible alarms enhance operational safety, while the energy-efficient refrigeration system and corrosion-resistant stainless steel construction ensure dependable long-term performance. Its combination of an internal drying chamber and four external flask connections makes the LFD-302 an excellent choice for research, pharmaceutical development, biotechnology, and university laboratories.

Why Choose Labotemp Small Freeze Dryer LFD-302?

✓ Flexible Sample Drying: Internal drying chamber with four external flask ports supports multiple sample types in a single system.
✓ Reliable Lyophilization: -88°C cold trap, 0.1 m² freeze-drying area, and ≤0.1 Pa ultimate vacuum deliver consistent drying performance.
✓ Intelligent Operation: 7-inch touchscreen PLC, programmable drying cycles, USB data export, and real-time process monitoring.

$15530

Datasheet

General Specifications
Type : External Flask Freeze Dryer Type	External Flask Freeze Dryer
Cold Trap Temperature : -88°C Cold Trap Temperature	-88°C
Shelf Temperature Range : -60°C to +70°C Shelf Temperature Range	-60°C to +70°C
Shelf Temperature Accuracy : < ±2°C Shelf Temperature Accuracy	< ±2°C
Ultimate Vacuum Degree : ≤0.1 Pa Ultimate Vacuum Degree	≤0.1 Pa
Vacuum Display Accuracy : 0.1 Pa Vacuum Display Accuracy	0.1 Pa
Pumping Speed : ≤15 min (Atmospheric pressure to 10 Pa) Pumping Speed	≤15 min (Atmospheric pressure to 10 Pa)
Freeze-Drying Area : 0.2 m² Freeze-Drying Area	0.2 m²
Maximum Ice Trapping Capacity : 4 kg Maximum Ice Trapping Capacity	4 kg
Water Trapping Capacity : 3 kg / 24 h Water Trapping Capacity	3 kg / 24 h
Chamber Capacity : 40 L Chamber Capacity	40 L
Cold Trap Capacity : 11 L Cold Trap Capacity	11 L
External Freeze-Drying Bottles : 4 External Freeze-Drying Bottles	4
Freeze-Drying Parameters
Vial Capacity Ø22 mm : 432 vials Vial Capacity Ø22 mm	432 vials
Vial Capacity Ø16 mm : 800 vials Vial Capacity Ø16 mm	800 vials
Vial Capacity Ø12 mm : 1452 vials Vial Capacity Ø12 mm	1452 vials
Shelf Dimension : 270 × 400 mm Shelf Dimension	270 × 400 mm
Shelf Layers : 2 layers Shelf Layers	2 layers
Shelf Spacing : 60 mm Shelf Spacing	60 mm
Drying Configuration : External flask freeze drying Drying Configuration	External flask freeze drying
Operation
Control System : 7-inch LCD touchscreen PLC control Control System	7-inch LCD touchscreen PLC control
Lyophilization Programs : Up to 40 customizable programs Lyophilization Programs	Up to 40 customizable programs
Programmable Process Segments : Up to 40 segments per program Programmable Process Segments	Up to 40 segments per program
Process Monitoring : Real-time vacuum pressure, shelf temperature, chamber temperature, and process time Process Monitoring	Real-time vacuum pressure, shelf temperature, chamber temperature, and process time
Data Management : Historical process records, data storage, and USB export Data Management	Historical process records, data storage, and USB export
Data Storage : More than 10,000 complete process records Data Storage	More than 10,000 complete process records
Vacuum Measurement : Pirani vacuum gauge Vacuum Measurement	Pirani vacuum gauge
Vacuum Protection : Anti-backstreaming protection during power interruption Vacuum Protection	Anti-backstreaming protection during power interruption
Defrost System : Electrically actuated cold trap defrosting Defrost System	Electrically actuated cold trap defrosting
Physical Dimensions
Overall Dimensions (W × D × H) : 820 × 695 × 995 mm Overall Dimensions (W × D × H)	820 × 695 × 995 mm
Shipping Dimensions (W × D × H) : 940 × 840 × 1230 mm Shipping Dimensions (W × D × H)	940 × 840 × 1230 mm
Freeze Dryer & Pump Dimensions : 610 × 230 × 310 mm Freeze Dryer & Pump Dimensions	610 × 230 × 310 mm
Gross Weight : 210 kg Gross Weight	210 kg

PLC Touchscreen ➤ PLC Touchscreen
Four external drying connections for flexible flask-based lyophilization ➤ Four external drying connections for flexible flask-based lyophilization
0.2 m² freeze-drying area for higher sample throughput ➤ 0.2 m² freeze-drying area for higher sample throughput
Two-layer shelf arrangement for organized sample processing ➤ Two-layer shelf arrangement for organized sample processing
-88°C cold trap for efficient condensation of sublimated moisture ➤ -88°C cold trap for efficient condensation of sublimated moisture
≤0.1 Pa ultimate vacuum for effective moisture removal ➤ ≤0.1 Pa ultimate vacuum for effective moisture removal
-60°C to +70°C shelf temperature control for versatile drying conditions ➤ -60°C to +70°C shelf temperature control for versatile drying conditions
7-inch touchscreen PLC system for intuitive process management ➤ 7-inch touchscreen PLC system for intuitive process management
Up to 40 customizable programs with up to 40 programmable segments per program ➤ Up to 40 customizable programs with up to 40 programmable segments per program
Historical process recording with storage for more than 10,000 complete records ➤ Historical process recording with storage for more than 10,000 complete records
USB export for convenient process documentation and traceability ➤ USB export for convenient process documentation and traceability

Pharmaceutical Development: Suitable for lyophilization of pharmaceutical formulations, APIs, vaccines, and moisture-sensitive compounds using external flasks Pharmaceutical Development
Suitable for lyophilization of pharmaceutical formulations, APIs, vaccines, and moisture-sensitive compounds using external flasks
Biotechnology: Supports drying of enzymes, proteins, biological materials, cultures, and other sensitive biomolecules Biotechnology
Supports drying of enzymes, proteins, biological materials, cultures, and other sensitive biomolecules
Research Laboratories: Useful for experimental sample preparation, formulation studies, process development, and controlled lyophilization research Research Laboratories
Useful for experimental sample preparation, formulation studies, process development, and controlled lyophilization research
University Laboratories: Suitable for teaching, research, sample preservation, and development of freeze-drying protocols University Laboratories
Suitable for teaching, research, sample preservation, and development of freeze-drying protocols
Plant & Natural Product Research: Used for drying plant extracts, botanical materials, and natural compounds while minimizing thermal degradation Plant & Natural Product Research
Used for drying plant extracts, botanical materials, and natural compounds while minimizing thermal degradation
Food & Nutraceutical Research: Supports lyophilization of probiotics, extracts, nutritional ingredients, and other heat-sensitive materials Food & Nutraceutical Research
Supports lyophilization of probiotics, extracts, nutritional ingredients, and other heat-sensitive materials
Chemical Research: Suitable for moisture removal from laboratory chemicals, solutions, and specialized research preparations Chemical Research
Suitable for moisture removal from laboratory chemicals, solutions, and specialized research preparations
External Flask Processing: Particularly suitable for liquid samples and formulations requiring multiple flask connections during freeze drying External Flask Processing
Particularly suitable for liquid samples and formulations requiring multiple flask connections during freeze drying
