Specifications
|
Model :
BTA-02
Model |
BTA-02 |
|
Capacity :
12L
Capacity |
12L |
|
Rated Working Temperature :
134°C
Rated Working Temperature |
134°C |
|
Voltage :
220V 110V, 50Hz/60Hz
Voltage |
220V 110V, 50Hz/60Hz |
|
Power :
2KW
Power |
2KW |
|
Rated Working Pressure :
0.22 MPa
Rated Working Pressure |
0.22 MPa |
|
Design Temperature :
139°C
Design Temperature |
139°C |
|
Design Pressure :
0.25 MPa
Design Pressure |
0.25 MPa |
|
Chamber Volume :
Φ200 × 355 mm
Chamber Volume |
Φ200 × 355 mm |
|
Outer Dimension :
455 × 580 × 400 mm
Outer Dimension |
455 × 580 × 400 mm |
|
Packing Size (L × W × H) :
650 × 500 × 450 mm
Packing Size (L × W × H) |
650 × 500 × 450 mm |
|
Net Weight :
44kg
Net Weight |
44kg |
|
Gross Weight :
48kg
Gross Weight |
48kg |
Features
-
Class N Standard
➤ Class N Standard
-
Microcomputer controlled sterilization system for accurate operation
➤ Microcomputer controlled sterilization system for accurate operation
-
Adjustable sterilization temperatures of 121°C and 134°C
➤ Adjustable sterilization temperatures of 121°C and 134°C
-
Built-in rapid steam generation system for efficient sterilization
➤ Built-in rapid steam generation system for efficient sterilization
-
Automatic sterilization cycle with user-friendly touch button control
➤ Automatic sterilization cycle with user-friendly touch button control
-
Safety interlocking door mechanism for secure operation
➤ Safety interlocking door mechanism for secure operation
-
Equipped with over-temperature and over-pressure protection system
➤ Equipped with over-temperature and over-pressure protection system
-
Low water level and anti-dry burning protection for enhanced safety
➤ Low water level and anti-dry burning protection for enhanced safety
-
Automatic cold air discharge and automatic steam exhaust after sterilization
➤ Automatic cold air discharge and automatic steam exhaust after sterilization
-
Audible buzzer indication with automatic stop function after cycle completion
➤ Audible buzzer indication with automatic stop function after cycle completion
-
Standard test interface provided for routine testing and validation
➤ Standard test interface provided for routine testing and validation
Applications
-
BTA-02 is suitable for sterilization of dental instruments, surgical tools, laboratory glassware, microbiology media and reusable medical devices in clinics, hospitals, diagnostic laboratories, research centers and academic institutions
➤ BTA-02 is suitable for sterilization of dental instruments, surgical tools, laboratory glassware, microbiology media and reusable medical devices in clinics, hospitals, diagnostic laboratories, research centers and academic institutions
-
Ideal for routine Class N sterilization processes requiring compact operation, automatic cycle control and reliable saturated steam sterilization
➤ Ideal for routine Class N sterilization processes requiring compact operation, automatic cycle control and reliable saturated steam sterilization
- Class N Standard
- Microcomputer controlled sterilization system for accurate operation
- Adjustable sterilization temperatures of 121°C and 134°C
- Built-in rapid steam generation system for efficient sterilization
- Automatic sterilization cycle with user-friendly touch button control
- Safety interlocking door mechanism for secure operation
- Equipped with over-temperature and over-pressure protection system
- Low water level and anti-dry burning protection for enhanced safety
- Automatic cold air discharge and automatic steam exhaust after sterilization
- Audible buzzer indication with automatic stop function after cycle completion
- Standard test interface provided for routine testing and validation
BTA-02 is suitable for sterilization of dental instruments, surgical tools, laboratory glassware, microbiology media and reusable medical devices in clinics, hospitals, diagnostic laboratories, research centers and academic institutions. Ideal for routine Class N sterilization processes requiring compact operation, automatic cycle control and reliable saturated steam sterilization.
