Specifications
|
Model :
BTA-04
Model |
BTA-04 |
|
Capacity :
23L
Capacity |
23L |
|
Rated Working Temperature :
134°C
Rated Working Temperature |
134°C |
|
Voltage :
220V 110V, 50Hz/60Hz
Voltage |
220V 110V, 50Hz/60Hz |
|
Power :
2KW
Power |
2KW |
|
Rated Working Pressure :
0.22 MPa
Rated Working Pressure |
0.22 MPa |
|
Design Temperature :
139°C
Design Temperature |
139°C |
|
Design Pressure :
0.25 MPa
Design Pressure |
0.25 MPa |
|
Chamber Volume :
Φ250 × 452 mm
Chamber Volume |
Φ250 × 452 mm |
|
Outer Dimension :
480 × 690 × 450 mm
Outer Dimension |
480 × 690 × 450 mm |
|
Packing Size (L × W × H) :
760 × 560 × 510 mm
Packing Size (L × W × H) |
760 × 560 × 510 mm |
|
Net Weight :
53kg
Net Weight |
53kg |
|
Gross Weight :
60kg
Gross Weight |
60kg |
Features
-
Safety Door Lock
➤ Safety Door Lock
-
Delivers saturated steam sterilization at 121°C and 134°C
➤ Delivers saturated steam sterilization at 121°C and 134°C
-
Microcomputer-controlled automatic sterilization cycles
➤ Microcomputer-controlled automatic sterilization cycles
-
Built-in steam generator for rapid steam production
➤ Built-in steam generator for rapid steam production
-
Class N sterilization standard for routine medical and laboratory use
➤ Class N sterilization standard for routine medical and laboratory use
-
Automatic cold air discharge and post-cycle steam exhaust system
➤ Automatic cold air discharge and post-cycle steam exhaust system
-
Safety interlocking door mechanism for secure operation
➤ Safety interlocking door mechanism for secure operation
-
Over-temperature, over-pressure and low water level protection
➤ Over-temperature, over-pressure and low water level protection
-
Touch button control panel with user-friendly operation
➤ Touch button control panel with user-friendly operation
-
Sealed chamber design for reliable sterilization performance
➤ Sealed chamber design for reliable sterilization performance
-
Equipped with standard test interface for monitoring applications
➤ Equipped with standard test interface for monitoring applications
-
Automatic stop function with buzzer reminder after sterilization
➤ Automatic stop function with buzzer reminder after sterilization
-
Compact tabletop design suitable for space-saving installation
➤ Compact tabletop design suitable for space-saving installation
Applications
-
BTA-04 is suitable for sterilization of surgical instruments, dental tools, laboratory glassware, microbiology media and reusable medical devices in hospitals, diagnostic centers, dental clinics, research laboratories and academic institutions
➤ BTA-04 is suitable for sterilization of surgical instruments, dental tools, laboratory glassware, microbiology media and reusable medical devices in hospitals, diagnostic centers, dental clinics, research laboratories and academic institutions
-
Ideal for routine Class N sterilization processes requiring automatic cycle control, saturated steam sterilization, process monitoring and safe operation in high-frequency clinical and laboratory environments
➤ Ideal for routine Class N sterilization processes requiring automatic cycle control, saturated steam sterilization, process monitoring and safe operation in high-frequency clinical and laboratory environments
- Safety Door Lock
- Delivers saturated steam sterilization at 121°C and 134°C
- Microcomputer-controlled automatic sterilization cycles
- Built-in steam generator for rapid steam production
- Class N sterilization standard for routine medical and laboratory use
- Automatic cold air discharge and post-cycle steam exhaust system
- Safety interlocking door mechanism for secure operation
- Over-temperature, over-pressure and low water level protection
- Touch button control panel with user-friendly operation
- Sealed chamber design for reliable sterilization performance
- Equipped with standard test interface for monitoring applications
- Automatic stop function with buzzer reminder after sterilization
- Compact tabletop design suitable for space-saving installation
BTA-04 is suitable for sterilization of surgical instruments, dental tools, laboratory glassware, microbiology media and reusable medical devices in hospitals, diagnostic centers, dental clinics, research laboratories and academic institutions. Ideal for routine Class N sterilization processes requiring automatic cycle control, saturated steam sterilization, process monitoring and safe operation in high-frequency clinical and laboratory environments.
