Horizontal Autoclave HZA-04

Name: Horizontal Autoclave HZA-04
Brand: Labotemp
SKU: HZA-04
Price: 10250.00 USD
Availability: InStock
Rating: 4.9 (981 reviews)

Labotemp Horizontal Autoclave HZA-04 is a 400L horizontal pressure steam sterilizer built for laboratory, medical, and industrial sterilization environments. Operating at 134°C with a working pressure of 0.22 MPa and an adjustable temperature range of 115°C–134°C, it delivers consistent and reliable sterilization across a broad range of load types. The stainless steel chamber (Φ700×1100mm) accommodates large and bulk loads including instruments, media, dressings, biological waste, and rubber components, supporting high-volume workflows with ease.

The HZA-04 supports an optional printer accessory that automatically records time and chamber temperature data for every processing cycle, ensuring complete documentation and traceability. Over-temperature and over-pressure auto-protection devices, a pressure-locked door mechanism, automatic water and power cut-off, and a safety valve that exhausts excess steam to the water tank provide multi-layer protection throughout every cycle. The unit operates on 380V/50Hz and is built for straightforward integration into existing facility setups.

Why Choose Labotemp Horizontal Autoclave HZA-04?
✓ Cycle Documentation: Integrated printer records time and temperature data for every sterilization cycle, supporting traceability and compliance.
✓ Trusted Manufacturer: ISO 13485:2016 and CE-compliant products built to global medical device standards.
✓ Proven Safety: Pressure-locked door, auto power cut-off, water alarm, and over-pressure valve deliver multi-layer protection.

$10250

Datasheet

General Specifications
Working Temperature : 134°C Working Temperature	134°C
Capacity : 400 L Capacity	400 L
Working Pressure : 0.22 MPa Working Pressure	0.22 MPa
Sterilization Time : 0–60 min Sterilization Time	0–60 min
Heat Average : ≤ ±1°C Heat Average	≤ ±1°C
Drying Time : 0–60 min Drying Time	0–60 min
Temperature Adjustment : 115°C–134°C Temperature Adjustment	115°C–134°C
Chamber Size (mm) : Φ700 × 1100 Chamber Size (mm)	Φ700 × 1100
Electrical & Construction
Voltage : 380 V / 50 Hz Voltage	380 V / 50 Hz
Power : 18 kW Power	18 kW
Packaging Information
Dimension (mm) : 1430 × 880 × 1830 Dimension (mm)	1430 × 880 × 1830
Transport Dimension (mm) : 1800 × 1050 × 2100 Transport Dimension (mm)	1800 × 1050 × 2100
Net Weight : 420 kg Net Weight	420 kg
Gross Weight : 530 kg Gross Weight	530 kg

Pressure-Safe Door Lock ➤ Pressure-Safe Door Lock
Pressure-safe door lock prevents opening during pressurized operation. ➤ Pressure-safe door lock prevents opening during pressurized operation.
Fully automatic sterilization control simplifies operation and minimizes manual intervention. ➤ Fully automatic sterilization control simplifies operation and minimizes manual intervention.
Integrated drying function supports efficient post-sterilization drying of compatible materials. ➤ Integrated drying function supports efficient post-sterilization drying of compatible materials.
Over-temperature and over-pressure protection safeguards the chamber and sterilized loads. ➤ Over-temperature and over-pressure protection safeguards the chamber and sterilized loads.
Pressure-locked door mechanism prevents opening until chamber pressure reaches a safe level. ➤ Pressure-locked door mechanism prevents opening until chamber pressure reaches a safe level.
Automatic safety valve releases excess pressure when the internal pressure exceeds the specified limit. ➤ Automatic safety valve releases excess pressure when the internal pressure exceeds the specified limit.
Automatic power and water cut-off provides protection when insufficient water supply is detected. ➤ Automatic power and water cut-off provides protection when insufficient water supply is detected.
Stainless-steel sterilization chamber provides durability, corrosion resistance, and easy cleaning. ➤ Stainless-steel sterilization chamber provides durability, corrosion resistance, and easy cleaning.
134°C saturated steam sterilization supports reliable elimination of microorganisms from compatible loads. ➤ 134°C saturated steam sterilization supports reliable elimination of microorganisms from compatible loads.
0–60 minute adjustable sterilization and drying times provide flexible cycle management. ➤ 0–60 minute adjustable sterilization and drying times provide flexible cycle management.
Optional printer supports sterilization cycle documentation and traceability. ➤ Optional printer supports sterilization cycle documentation and traceability.
High-capacity 400 L chamber accommodates bulk sterilization requirements across demanding facilities ➤ High-capacity 400 L chamber accommodates bulk sterilization requirements across demanding facilities

Hospital & CSSD Facilities: Suitable for high-volume sterilization of compatible medical instruments, dressings, glassware, and reusable equipment Hospital & CSSD Facilities
Suitable for high-volume sterilization of compatible medical instruments, dressings, glassware, and reusable equipment
Pharmaceutical Laboratories: Supports sterilization of laboratory instruments, glassware, culture media, and compatible production materials Pharmaceutical Laboratories
Supports sterilization of laboratory instruments, glassware, culture media, and compatible production materials
Microbiology & Research Laboratories: Suitable for processing culture media, laboratory instruments, biological waste, and other heat- and moisture-compatible materials Microbiology & Research Laboratories
Suitable for processing culture media, laboratory instruments, biological waste, and other heat- and moisture-compatible materials
Healthcare Facilities: Designed for reliable sterilization of compatible medical and surgical materials requiring high-capacity steam processing Healthcare Facilities
Designed for reliable sterilization of compatible medical and surgical materials requiring high-capacity steam processing
Industrial Applications: Suitable for sterilizing rubber components, laboratory accessories, and other compatible materials in industrial environments Industrial Applications
Suitable for sterilizing rubber components, laboratory accessories, and other compatible materials in industrial environments
High-Volume Sterilization: The 400 L chamber is well suited to facilities requiring bulk-load processing, consistent sterilization, integrated drying, and reliable cycle documentation High-Volume Sterilization
The 400 L chamber is well suited to facilities requiring bulk-load processing, consistent sterilization, integrated drying, and reliable cycle documentation
