Specifications
|
Temperature Range :
+60°C
Temperature Range |
+60°C |
|
Interior Volume :
410L
Interior Volume |
410L |
|
Internal Dimensions (mm) :
1100×750×500
Internal Dimensions (mm) |
1100×750×500 |
|
Overall Dimensions (mm) :
1950×1030×1350
Overall Dimensions (mm) |
1950×1030×1350 |
|
Temperature Fluctuation :
±0.5°C
Temperature Fluctuation |
±0.5°C |
|
Temperature Deviation :
±2.0°C
Temperature Deviation |
±2.0°C |
|
Humidity Range :
95% ~ 98% RH
Humidity Range |
95% ~ 98% RH |
|
Salt Fog Deposition :
1 ~ 2 ml / 80 cm² · h
Salt Fog Deposition |
1 ~ 2 ml / 80 cm² · h |
|
Spray Type :
Continuous / Periodic
Spray Type |
Continuous / Periodic |
|
Salt Fog Collected :
Fog collector and fog measure cylinder
Salt Fog Collected |
Fog collector and fog measure cylinder |
|
Air Preheating :
Saturated air barrel
Air Preheating |
Saturated air barrel |
|
Spraying System :
Atomizer tower and Spray nozzles
Spraying System |
Atomizer tower and Spray nozzles |
|
Controller :
PID controller
Controller |
PID controller |
|
Safety Device :
Humidifier Dry-combustion Protection; Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection
Safety Device |
Humidifier Dry-combustion Protection; Over-temperature Protection; Over-current Protection; Water Shortage Protection; Earth leakage Protection |
|
Material :
Glass fiber reinforced plastics
Material |
Glass fiber reinforced plastics |
|
Voltage :
220, 60Hz
Voltage |
220, 60Hz |
|
Net Weight :
203kg
Net Weight |
203kg |
|
Gross Weight :
292kg
Gross Weight |
292kg |
Features
-
Massive 780L Volume
➤ Massive 780L Volume
-
Continuous or periodic salt spray testing for corrosion evaluation
➤ Continuous or periodic salt spray testing for corrosion evaluation
-
PID controller for stable and precise temperature regulation
➤ PID controller for stable and precise temperature regulation
-
Salt fog deposition rate of 1–2 ml / 80 cm²·h for accurate corrosion testing
➤ Salt fog deposition rate of 1–2 ml / 80 cm²·h for accurate corrosion testing
-
Saturated air barrel for air preheating to ensure uniform fog generation
➤ Saturated air barrel for air preheating to ensure uniform fog generation
-
Atomizer tower and spray nozzles providing consistent fog distribution
➤ Atomizer tower and spray nozzles providing consistent fog distribution
-
Glass fiber reinforced plastic chamber body for strong corrosion resistance
➤ Glass fiber reinforced plastic chamber body for strong corrosion resistance
-
95%–98% RH humidity range for high-salt, high-moisture testing
➤ 95%–98% RH humidity range for high-salt, high-moisture testing
-
Multiple safety protections: dry-combustion, over-temperature, over-current, water shortage, and earth leakage protection
➤ Multiple safety protections: dry-combustion, over-temperature, over-current, water shortage, and earth leakage protection
-
Fog collector and measuring cylinder for monitoring deposition rate
➤ Fog collector and measuring cylinder for monitoring deposition rate
Applications
-
Used in corrosion resistance testing of metals and coatings, evaluation of paints and surface treatments, durability testing of automotive parts and hardware, corrosion testing of electronic components, quality control for plating and coating processes, material assessment for marine/coastal environments
➤ Used in corrosion resistance testing of metals and coatings, evaluation of paints and surface treatments, durability testing of automotive parts and hardware, corrosion testing of electronic components, quality control for plating and coating processes, material assessment for marine/coastal environments
- Massive 780L Volume
- Continuous or periodic salt spray testing for corrosion evaluation
- PID controller for stable and precise temperature regulation
- Salt fog deposition rate of 1–2 ml / 80 cm²·h for accurate corrosion testing
- Saturated air barrel for air preheating to ensure uniform fog generation
- Atomizer tower and spray nozzles providing consistent fog distribution
- Glass fiber reinforced plastic chamber body for strong corrosion resistance
- 95%–98% RH humidity range for high-salt, high-moisture testing
- Multiple safety protections: dry-combustion, over-temperature, over-current, water shortage, and earth leakage protection
- Fog collector and measuring cylinder for monitoring deposition rate
Used in corrosion resistance testing of metals and coatings, evaluation of paints and surface treatments, durability testing of automotive parts and hardware, corrosion testing of electronic components, quality control for plating and coating processes, material assessment for marine/coastal environments.
- Spray nozzle
- Measuring cylinder
- Solid-state relay
- Contactor
- Heating tube of Saturated barrel
