Temperature Range |
-120°C ~ +150°C |
|
Interior Volume |
500L |
|
Power Supply |
380V 50Hz |
|
Internal Dimension (mm) |
700×800×900 |
|
Overall Dimension (mm) |
1200×1340×2020 |
|
Temperature Fluctuation |
±0.5°C |
|
Temperature Deviation |
±2.0°C |
|
Cooling Rate |
1°C / min |
|
Heating Rate |
3°C / min |
|
Cooling System |
Mechanical compression refrigeration system |
|
Refrigerating Unit |
Cascade compressor |
|
Heating Element |
Nichrome heater |
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection, PC Link |
|
Temperature Sensor |
PTR Platinum Resistance PT100Ω / MV A-class |
|
Air Circulation |
Centrifugal wind fan |
|
Exterior Material |
Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
|
Thermal Insulation |
Polyurethane foam and insulation cotton |
|
Observation Window |
Interior lighting, double-layer thermo stability silicone rubber sealing |
|
Standard Configuration |
1 Cable hole (Φ50) with plug; 2 shelves |
|
Maximum Noise |
65 dBA |
|
Safety Device |
Over-temperature Protection; Over-current Protection; Refrigerant High-Pressure Protection; Earth leakage Protection |
|
Net Weight |
534kg |
|
Gross Weight |
774kg |
- ➤ No Liquid Nitrogen
- ➤ Mechanical compressor cooling to –120°C (no liquid nitrogen)
- ➤ Wide temperature range –120°C to +150°C
- ➤ High-accuracy PT100 sensor (0
- ➤ 001°C)
- ➤ 7-inch PID touch controller with Ethernet & USB
- ➤ French TECUMSEH compressor with eco-friendly refrigerant
- ➤ Uniform air circulation using centrifugal fan
- ➤ SUS304 stainless steel interior with adjustable shelves
- ➤ Double-layer glass window with anti-frost film & LED light
- ➤ Nichrome heater for fast and stable heating
- ➤ Multiple safety protections (over-temp, over-current, high-pressure, earth leakage)
- ➤ 10cm polyurethane insulation for high efficiency
- ➤ A3 galvanized steel exterior for durability
- ➤ Movable castors with brakes for easy handling
- ➤ Used in Aerospace material testing, military equipment reliability testing, electronic component performance testing, high-precision industry low-temperature testing, high-end processing and quenching processes, and extreme environment simulation for product stability
- No Liquid Nitrogen
- Mechanical compressor cooling to –120°C (no liquid nitrogen)
- Wide temperature range –120°C to +150°C
- High-accuracy PT100 sensor (0.001°C)
- 7-inch PID touch controller with Ethernet & USB
- French TECUMSEH compressor with eco-friendly refrigerant
- Uniform air circulation using centrifugal fan
- SUS304 stainless steel interior with adjustable shelves
- Double-layer glass window with anti-frost film & LED light
- Nichrome heater for fast and stable heating
- Multiple safety protections (over-temp, over-current, high-pressure, earth leakage)
- 10cm polyurethane insulation for high efficiency
- A3 galvanized steel exterior for durability
- Movable castors with brakes for easy handling
Used in Aerospace material testing, military equipment reliability testing, electronic component performance testing, high-precision industry low-temperature testing, high-end processing and quenching processes, and extreme environment simulation for product stability.
- Temperature sensor
- Solid-state relay
- Contactor
