Specifications
|
Model :
CFR-06
Model |
CFR-06 |
|
Capacity :
280L (upper) 120L (Lower)
Capacity |
280L (upper) 120L (Lower) |
|
Temperature Range :
Upper: 2–8°C / Lower: -5 to -25°C
Temperature Range |
Upper: 2–8°C / Lower: -5 to -25°C |
|
Power Supply :
220V 50Hz
Power Supply |
220V 50Hz |
|
Ambient Temperature :
16–32°C
Ambient Temperature |
16–32°C |
|
Input Power :
550 W
Input Power |
550 W |
|
Type :
Cryobiology Cooling Device
Type |
Cryobiology Cooling Device |
|
Over-Temperature Alarm :
With Alarm Function
Over-Temperature Alarm |
With Alarm Function |
|
Alarm :
Audible and Visual Alarm for High and Low Temperature
Alarm |
Audible and Visual Alarm for High and Low Temperature |
|
Thermostat :
Electronic
Thermostat |
Electronic |
|
Condensing Fan :
Germany EBM Brand Fan
Condensing Fan |
Germany EBM Brand Fan |
|
Inner Material :
304 Stainless Steel
Inner Material |
304 Stainless Steel |
|
Exterior Material :
Galvanized Sheet Sprayed
Exterior Material |
Galvanized Sheet Sprayed |
|
Internal dimensions (upper/ lower) :
660 × 610 × 800 / 553 × 524 × 425 mm
Internal dimensions (upper/ lower) |
660 × 610 × 800 / 553 × 524 × 425 mm |
|
External dimensions :
770 × 715 × 1980 mm
External dimensions |
770 × 715 × 1980 mm |
|
Net Weight :
135 kg
Net Weight |
135 kg |
|
Gross Weight :
175kg
Gross Weight |
175kg |
Features
-
Integrated Cooling
➤ Integrated Cooling
-
Dual-temperature design with separate refrigerator and freezer storage compartments
➤ Dual-temperature design with separate refrigerator and freezer storage compartments
-
Upper chamber temperature range: 2°C to 8°C; lower chamber: -10°C to -40°C
➤ Upper chamber temperature range: 2°C to 8°C; lower chamber: -10°C to -40°C
-
Microcomputer-based electronic temperature controller with digital data display
➤ Microcomputer-based electronic temperature controller with digital data display
-
High-density 120 mm foaming insulation layer for improved thermal retention
➤ High-density 120 mm foaming insulation layer for improved thermal retention
-
SECOP compressor with stable low-noise operation and long service life
➤ SECOP compressor with stable low-noise operation and long service life
-
Fluorine-free environmentally friendly refrigerant system
➤ Fluorine-free environmentally friendly refrigerant system
-
PTC probe ensures accurate temperature sensing and monitoring
➤ PTC probe ensures accurate temperature sensing and monitoring
-
Audible and visual alarm system for temperature deviation and operational faults
➤ Audible and visual alarm system for temperature deviation and operational faults
-
Supports power outage, door opening, and sensor fault alarm protection
➤ Supports power outage, door opening, and sensor fault alarm protection
-
Powder-coated steel exterior with corrosion-resistant finish
➤ Powder-coated steel exterior with corrosion-resistant finish
-
304 stainless steel interior for hygienic and durable sample storage
➤ 304 stainless steel interior for hygienic and durable sample storage
-
Equipped with 3 shelves and 2 stainless steel inner doors for organized storage
➤ Equipped with 3 shelves and 2 stainless steel inner doors for organized storage
-
Wide voltage compatibility suitable for unstable power conditions
➤ Wide voltage compatibility suitable for unstable power conditions
-
Built-in balance hole for pressure equalization and easier door opening
➤ Built-in balance hole for pressure equalization and easier door opening
Applications
-
Suitable for simultaneous refrigerated and frozen storage of vaccines, medicines, reagents, biological samples, and laboratory materials in hospitals, pharmacies, diagnostic centers, CDC facilities, and research laboratories
➤ Suitable for simultaneous refrigerated and frozen storage of vaccines, medicines, reagents, biological samples, and laboratory materials in hospitals, pharmacies, diagnostic centers, CDC facilities, and research laboratories
-
Ideal for healthcare cold-chain applications requiring dual-temperature storage, real-time monitoring, alarm protection, and secure preservation of temperature-sensitive products
➤ Ideal for healthcare cold-chain applications requiring dual-temperature storage, real-time monitoring, alarm protection, and secure preservation of temperature-sensitive products
- Integrated Cooling
- Dual-temperature design with separate refrigerator and freezer storage compartments
- Upper chamber temperature range: 2°C to 8°C; lower chamber: -10°C to -40°C
- Microcomputer-based electronic temperature controller with digital data display
- High-density 120 mm foaming insulation layer for improved thermal retention
- SECOP compressor with stable low-noise operation and long service life
- Fluorine-free environmentally friendly refrigerant system
- PTC probe ensures accurate temperature sensing and monitoring
- Audible and visual alarm system for temperature deviation and operational faults
- Supports power outage, door opening, and sensor fault alarm protection
- Powder-coated steel exterior with corrosion-resistant finish
- 304 stainless steel interior for hygienic and durable sample storage
- Equipped with 3 shelves and 2 stainless steel inner doors for organized storage
- Wide voltage compatibility suitable for unstable power conditions
- Built-in balance hole for pressure equalization and easier door opening
Suitable for simultaneous refrigerated and frozen storage of vaccines, medicines, reagents, biological samples, and laboratory materials in hospitals, pharmacies, diagnostic centers, CDC facilities, and research laboratories. Ideal for healthcare cold-chain applications requiring dual-temperature storage, real-time monitoring, alarm protection, and secure preservation of temperature-sensitive products.
