Vacuum Furnace

Labotemp's vacuum furnace systems deliver precise stable and energy-efficient thermal processing for laboratories, research institutes, production facilities. As experienced vacuum furnace manufacturer and supplier, we offer a complete range from compact laboratory vacuum furnaces to large high temperature vacuum furnace systems covering 1200–1700°C. Configurable for vacuum heat treatment, vacuum annealing, vacuum brazing furnace work, vacuum sintering, vacuum induction melting and our units support brazing, sintering, annealing, hardening and battery-material sintering. Constructed with flange-sealed box chambers, multi-layer alumina fiber insulation and HRE, SiC or MoSi2 heating, they deliver uniform temperature profiles. Intelligent PID/SCR/SSR controllers, N/B/S thermocouples, programmable multi-segment profiles, integrated vacuum furnace pumps, digital vacuum gauges and optional gas flow control enable accurate vacuum furnace operation from rough to high vacuum. ISO9001, ISO 13485, and CE certifications, modular safety systems and efficient design make Labotemp a trusted vacuum furnace supplier for research and industrial vacuum furnace solutions.

Shimaden Controller

Vacuum Furnace : Vacuum Furnace FVA-01

Vacuum Furnace FVA-01

Model NO. : FVA-01

Volume (L) : 3

Maximum Temperature (°C) : 1200

Working Temperature (°C) : 1100

$7527

Inert Gas Ready

Vacuum Furnace : Vacuum Furnace FVA-02

Vacuum Furnace FVA-02

Model NO. : FVA-02

Volume (L) : 8

Max Temp (°C) : 1200

Working Temp (°C) : 1100

$0

Water-Cooled Safety

Vacuum Furnace : Vacuum Furnace FVA-03

Vacuum Furnace FVA-03

Model NO. : FVA-03

Volume (L) : 12

Max Temp (°C) : 1200

Working Temp (°C) : 1100

Safety Interlocks

Vacuum Furnace : Vacuum Furnace FVA-04

Vacuum Furnace FVA-04

Model NO. : FVA-04

Volume (L) : 18

Max Temp (°C) : 1200

Working Temp (°C) : 1100

Digital gauge

Vacuum Furnace : Vacuum Furnace FVA-05

Vacuum Furnace FVA-05

Model NO. : FVA-05

Volume (L) : 30

Max Temp (°C) : 1200

Working Temp (°C) : 1100

S-type Thermocouple

Vacuum Furnace : Vacuum Furnace FVA-06

Vacuum Furnace FVA-06

Model NO. : FVA-06

Volume (L) : 3

Max Temp (°C) : 1400

Working Temp (°C) : 1350

Durable Box Design

Vacuum Furnace : Vacuum Furnace FVA-07

Vacuum Furnace FVA-07

Model NO. : FVA-07

Volume (L) : 8

Max Temp (°C) : 1400

Working Temp (°C) : 1300

$6625

Durable Steel Body

Vacuum Furnace : Vacuum Furnace FVA-08

Vacuum Furnace FVA-08

Model No. : FVA-08

Volume (L) : 12

Max Temp (°C) : 1400

Working Temp (°C) : 1350

Uniform Heat Zone

Vacuum Furnace : Vacuum Furnace FVA-09

Vacuum Furnace FVA-09

Model No. : FVA-09

Volume (L) : 18

Max Temp (°C) : 1400

Working Temp (°C) : 1300

Inert Gas Compatible

Vacuum Furnace : Vacuum Furnace FVA-10

Vacuum Furnace FVA-10

Model No. : FVA-10

Volume (L) : 36

Max Temp (°C) : 1400

Working Temp (°C) : 1350

Deep Vacuum Capability

Vacuum Furnace : Vacuum Furnace FVA-17

Vacuum Furnace FVA-17

Model No. : FVA-17

Volume (L) : 45

Max Temp (°C) : 1400

Working Temp (°C) : 1350

$16963

Rigid Insulation

Vacuum Furnace : Vacuum Furnace FVA-11

Vacuum Furnace FVA-11

Model No. : FVA-11

Volume (L) : 3

Maximum Temperature (°C) : 1700

Working Temperature (°C) : 1600

$10449

Pre-Vacuum System

Vacuum Furnace : Vacuum Furnace FVA-12

Vacuum Furnace FVA-12

Model No. : FVA-12

Volume (L) : 8

Max Temp (°C) : 1700

Working Temp (°C) : 1600

$8123

Supports Data Logging

Vacuum Furnace : Vacuum Furnace FVA-13

Vacuum Furnace FVA-13

Model No. : FVA-13

Volume (L) : 12

Max Temp (°C) : 1700

Working Temp (°C) : 1600

MoSi₂ Rod Heating

Vacuum Furnace : Vacuum Furnace FVA-14

Vacuum Furnace FVA-14

Model No. : FVA-14

Volume (L) : 20

Max Temp (°C) : 1700

Working Temp (°C) : 1600

Low-Oxidation Heat

Vacuum Furnace : Vacuum Furnace FVA-15

Vacuum Furnace FVA-15

Model No. : FVA-15

Volume (L) : 36

Max Temp (°C) : 1700

Working Temp (°C) : 1600

Chiller Compatible

Vacuum Furnace : Vacuum Furnace FVA-16

Vacuum Furnace FVA-16

Model No. : FVA-16

Volume (L) : 45

Max Temp (°C) : 1700

Working Temp (°C) : 1600
