Specifications
|
Model :
PHR-14
Model |
PHR-14 |
|
Capacity :
656 L
Capacity |
656 L |
|
Temperature Range :
2 ~ 8°C
Temperature Range |
2 ~ 8°C |
|
Power Supply :
220V 50Hz
Power Supply |
220V 50Hz |
|
Power Consumption :
403 W
Power Consumption |
403 W |
|
Sensor :
NTC
Sensor |
NTC |
|
Controller :
Microprocessor
Controller |
Microprocessor |
|
Refrigerant :
R290 (CFC Free)
Refrigerant |
R290 (CFC Free) |
|
Defrost :
Auto
Defrost |
Auto |
|
Compressor Quantity :
1
Compressor Quantity |
1 |
|
Display :
Digital Display
Display |
Digital Display |
|
Audible & Visible Alarm :
High/Low temperature, power failure, thermostat failure, door ajar
Audible & Visible Alarm |
High/Low temperature, power failure, thermostat failure, door ajar |
|
Power Failure Backup System (Alarm) :
8 h
Power Failure Backup System (Alarm) |
8 h |
|
Internal Material / External Material :
Electro-galvanized steel with antimicrobial powder coating
Internal Material / External Material |
Electro-galvanized steel with antimicrobial powder coating |
|
Test Hole (Qty / Diameter) :
1 / 25 mm
Test Hole (Qty / Diameter) |
1 / 25 mm |
|
Shelves Quantity :
10 Shelves
Shelves Quantity |
10 Shelves |
|
Sound Emission :
52 dB
Sound Emission |
52 dB |
|
Internal Size (W × D × H) :
1100 × 454 × 1325 mm
Internal Size (W × D × H) |
1100 × 454 × 1325 mm |
|
External Size (W × D × H) :
1220 × 630 × 1885 mm
External Size (W × D × H) |
1220 × 630 × 1885 mm |
|
Shipping Size (W × D × H) :
1280 × 670 × 1950 mm
Shipping Size (W × D × H) |
1280 × 670 × 1950 mm |
|
Net Weight :
166kg
Net Weight |
166kg |
|
Gross Weight :
184kg
Gross Weight |
184kg |
Features
-
Low Noise Cooling
➤ Low Noise Cooling
-
Automatic defrost system minimizes manual maintenance
➤ Automatic defrost system minimizes manual maintenance
-
Microprocessor-based control for reliable operation
➤ Microprocessor-based control for reliable operation
-
Audible and visible alarm system for enhanced storage protection
➤ Audible and visible alarm system for enhanced storage protection
-
8-hour power failure backup alarm support
➤ 8-hour power failure backup alarm support
-
Electro-galvanized steel construction with antimicrobial powder coating
➤ Electro-galvanized steel construction with antimicrobial powder coating
-
Equipped with 10 adjustable shelves for flexible storage arrangement
➤ Equipped with 10 adjustable shelves for flexible storage arrangement
-
Smooth mobility casters for convenient positioning and movement
➤ Smooth mobility casters for convenient positioning and movement
-
Digital display for real-time temperature observation
➤ Digital display for real-time temperature observation
-
High-efficiency R290 CFC-free refrigerant system for eco-friendly cooling
➤ High-efficiency R290 CFC-free refrigerant system for eco-friendly cooling
Applications
-
Suitable for refrigerated storage of vaccines, medicines, reagents, biological samples, and diagnostic materials in hospitals, pharmacies, blood banks, clinical laboratories, and research facilities
➤ Suitable for refrigerated storage of vaccines, medicines, reagents, biological samples, and diagnostic materials in hospitals, pharmacies, blood banks, clinical laboratories, and research facilities
-
Supports temperature-controlled healthcare storage, laboratory sample preservation, and monitored pharmaceutical cold chain applications requiring stable 2°C to 8°C operation with alarm-protected safety monitoring
➤ Supports temperature-controlled healthcare storage, laboratory sample preservation, and monitored pharmaceutical cold chain applications requiring stable 2°C to 8°C operation with alarm-protected safety monitoring
- Low Noise Cooling
- Automatic defrost system minimizes manual maintenance
- Microprocessor-based control for reliable operation
- Audible and visible alarm system for enhanced storage protection
- 8-hour power failure backup alarm support
- Electro-galvanized steel construction with antimicrobial powder coating
- Equipped with 10 adjustable shelves for flexible storage arrangement
- Smooth mobility casters for convenient positioning and movement
- Digital display for real-time temperature observation
- High-efficiency R290 CFC-free refrigerant system for eco-friendly cooling
Suitable for refrigerated storage of vaccines, medicines, reagents, biological samples, and diagnostic materials in hospitals, pharmacies, blood banks, clinical laboratories, and research facilities. Supports temperature-controlled healthcare storage, laboratory sample preservation, and monitored pharmaceutical cold chain applications requiring stable 2°C to 8°C operation with alarm-protected safety monitoring.
