Hydrothermal Reactor Autoclave HRA-07

Name: Hydrothermal Reactor Autoclave HRA-07
Brand: Labotemp
SKU: HRA-07
Price: 2617.00 USD
Availability: InStock
Rating: 4.9 (921 reviews)

Labotemp Hydrothermal Reactor Autoclave HRA-07 is a 500 mL, PTFE-lined hydrothermal reactor engineered for reliable hydrothermal synthesis, pressure digestion and catalytic reactions. Its thick-walled 316 stainless-steel kettle and secure gasketed lid resist strong acids and alkalis while preventing sample contamination. Rated for 200 °C operating (250 °C max) and 3.0 MPa, the HRA-07 accelerates fast, nondestructive dissolution of insoluble or volatile samples—ideal for trace-element analysis, materials research and high-purity workflows. Easy to operate and maintain, this teflon lined autoclave supports reproducible results across demanding lab tasks.

Designed for petrochemical, biomedical, geological, environmental and food labs, the HRA-07 handles heavy metals, pesticide residues, rare earths and complex organics with low contamination risk and reduced analysis time. Its robust construction, user-friendly maintenance and reliable temperature/pressure control make it a practical choice for routine sample pretreatment and hydrothermal synthesis projects. This hydrothermal autoclave reactor is engineered and designed by Labotemp, a specialized autoclave manufacturer for research laboratories.

Why Choose Labotemp Hydrothermal Reactor HRA-07?
✓ Certified safety: Complies with ISO 13485 and CE standards.
✓ Durable build: 316 stainless steel body with PTFE lining for long-term use.
✓ Reliable results: Fast, low-contamination digestion for consistent analysis.

$2617

Datasheet User Manual

General Specifications
Capacity : 500 ml Capacity	500 ml
Kettle Body Material : 316 Stainless Steel Kettle Body Material	316 Stainless Steel
Sterilization Parameters
Maximum Temperature : 250°C Maximum Temperature	250°C
Maximum Pressure : 3.0 MPa Maximum Pressure	3.0 MPa
Chamber Dimensions
Kettle Lid Height : 50 mm Kettle Lid Height	50 mm
Kettle Body Height : 161 mm Kettle Body Height	161 mm
Kettle Body Diameter : 118 mm Kettle Body Diameter	118 mm
Kettle Body Inner Diameter : 91 mm Kettle Body Inner Diameter	91 mm
Kettle Body Wall Thickness : 13.5 mm Kettle Body Wall Thickness	13.5 mm
Inner Diameter : 91 mm Inner Diameter	91 mm
Physical Dimensions
Overall Height : 220 mm Overall Height	220 mm
Length of Grip Bar : 8 × 120 mm Length of Grip Bar	8 × 120 mm
Lined With High : 136 mm Lined With High	136 mm
Lining Height / Thickness : 8 mm Lining Height / Thickness	8 mm
Thickness of Lower Gasket : 10 mm Thickness of Lower Gasket	10 mm
Thickness of Upper Gasket : 10 mm Thickness of Upper Gasket	10 mm
Packaging Information
Product Weight : 7.45 kg Product Weight	7.45 kg
Packing Dimension : 24.2 × 24.2 × 35.2 cm Packing Dimension	24.2 × 24.2 × 35.2 cm
Gross Weight : 13 kg Gross Weight	13 kg

Corrosion Safe 220C ➤ Corrosion Safe 220C
PTFE lining offers strong resistance to acids and alkalis for safe chemical reactions. ➤ PTFE lining offers strong resistance to acids and alkalis for safe chemical reactions.
Enables rapid dissolution of difficult-to-dissolve samples under elevated temperature and pressure conditions. ➤ Enables rapid dissolution of difficult-to-dissolve samples under elevated temperature and pressure conditions.
Designed with a compact and user-friendly structure for convenient operation and reliable analytical results. ➤ Designed with a compact and user-friendly structure for convenient operation and reliable analytical results.
Provides excellent sealing performance, preventing leakage and ensuring safe operation with minimal contamination. ➤ Provides excellent sealing performance, preventing leakage and ensuring safe operation with minimal contamination.

Hydrothermal Synthesis: Suitable for hydrothermal and solvothermal synthesis, crystal growth, nanomaterial preparation, and advanced material development requiring elevated temperature and pressure Hydrothermal Synthesis
Suitable for hydrothermal and solvothermal synthesis, crystal growth, nanomaterial preparation, and advanced material development requiring elevated temperature and pressure
High-Pressure Sample Digestion: Designed for digestion and dissolution of trace elements, heavy metals, geological samples, and other difficult-to-dissolve materials High-Pressure Sample Digestion
Designed for digestion and dissolution of trace elements, heavy metals, geological samples, and other difficult-to-dissolve materials
Petrochemical Research: Supports high-temperature and high-pressure reactions, sample preparation, and material evaluation in petrochemical laboratories Petrochemical Research
Supports high-temperature and high-pressure reactions, sample preparation, and material evaluation in petrochemical laboratories
Materials Science: Suitable for synthesis and processing of catalysts, ceramics, inorganic compounds, nanomaterials, and other advanced materials Materials Science
Suitable for synthesis and processing of catalysts, ceramics, inorganic compounds, nanomaterials, and other advanced materials
Geological & Environmental Laboratories: Supports preparation and digestion of mineral, soil, sediment, and environmental samples for subsequent laboratory analysis Geological & Environmental Laboratories
Supports preparation and digestion of mineral, soil, sediment, and environmental samples for subsequent laboratory analysis
Chemical Research: Suitable for controlled high-pressure chemical reactions, dissolution studies, reaction screening, and laboratory-scale synthesis Chemical Research
Suitable for controlled high-pressure chemical reactions, dissolution studies, reaction screening, and laboratory-scale synthesis
Food & Agricultural Research: Useful for high-pressure sample digestion and preparation of compatible food, agricultural, and environmental samples Food & Agricultural Research
Useful for high-pressure sample digestion and preparation of compatible food, agricultural, and environmental samples
Academic & Research Laboratories: The 500 mL capacity provides practical higher-volume processing for university, research, and industrial laboratory experiments Academic & Research Laboratories
The 500 mL capacity provides practical higher-volume processing for university, research, and industrial laboratory experiments
