Labotemp Hydrothermal Reactor Autoclave HRA-08 provides a safe and reliable solution for high-temperature, high-pressure chemical synthesis in research and analytical laboratories. Featuring a 2000 mL working volume, 220°C safe operating temperature, and 3 MPa maximum working pressure, the reactor supports demanding laboratory processes with consistent performance. Constructed with a durable 304 stainless steel outer vessel and a chemically resistant PTFE liner, it offers excellent resistance to acids, alkalis, and corrosive chemicals while minimizing sample contamination. This hydrothermal autoclave is widely used for nanomaterial preparation, crystal growth, compound synthesis, material development, and other hydrothermal synthesis applications across universities, research institutes, and industrial laboratories.
Designed for long-term laboratory use, the HRA-08 features a precision sealing system that helps maintain stable pressure throughout the reaction process while ensuring safe operation. The removable PTFE liner simplifies sample loading, cleaning, and maintenance, while the corrosion-resistant construction supports repeated use with aggressive chemical media. With a recommended heating and cooling rate of ≤5°C/min, the hydrothermal reactor promotes controlled reaction conditions and reproducible experimental results.
Why Choose Labotemp Hydrothermal Reactor Autoclave HRA-08?
✓ High Temperature & Pressure: Operates safely up to 220°C and 3 MPa for demanding laboratory reactions.
✓ Chemical-Resistant Construction: 304 stainless steel body with a PTFE liner provides excellent corrosion resistance.
✓ Reliable Laboratory Performance: Precision sealing system, removable liner, and controlled heating/cooling support repeatable experimental results.
| Reactor & Operating Performance | |
|
Capacity : 2000 mL Capacity |
2000 mL |
|
Maximum Working Pressure : 3 MPa Maximum Working Pressure |
3 MPa |
|
Safe Working Temperature : 220 °C Safe Working Temperature |
220 °C |
| Liner & Construction | |
|
Liner Outer Diameter : 180 mm Liner Outer Diameter |
180 mm |
|
Liner Height : 141 mm Liner Height |
141 mm |
|
Material : 304 Stainless Steel, PTFE Liner Material |
304 Stainless Steel, PTFE Liner |
| Dimensions & Weight | |
|
Height : 220 mm Height |
220 mm |
|
Outer Diameter of Reactor : 270 mm Outer Diameter of Reactor |
270 mm |
|
Net Weight : 32 kg Net Weight |
32 kg |
|
Gross Weight : 40 kg Gross Weight |
40 kg |
|
Packing Dimension : 33 × 27 × 32 cm Packing Dimension |
33 × 27 × 32 cm |
| Operating Information | |
|
Recommended Filling Volume : 60% to 80% of Liner Capacity Recommended Filling Volume |
60% to 80% of Liner Capacity |
|
Maximum Filling Volume : 80% of Liner Capacity Maximum Filling Volume |
80% of Liner Capacity |
|
Recommended Heating and Cooling Rate : ≤5 °C/min Recommended Heating and Cooling Rate |
≤5 °C/min |
|
Heating Equipment : Laboratory Drying Oven Heating Equipment |
Laboratory Drying Oven |
|
Liner Options : PTFE / PPL Liner Options |
PTFE / PPL |
| Safety & Construction | |
|
Sealing Design : Leak Proof Sealing Design |
Leak Proof |
|
Outer Vessel : Stainless Steel Outer Vessel |
Stainless Steel |
|
Liner : Removable PTFE / PPL Liner |
Removable PTFE / PPL |
|
Pressure Monitoring : Pressure Gauge Pressure Monitoring |
Pressure Gauge |
|
Clamp : Stainless Steel Clamp Clamp |
Stainless Steel Clamp |
Thickness of Upper Gasket: 8 mm
Thickness of Lower Gasket: 8 mm
Sterilization Parameters:
Product Weight: 0.95 kg
Upper Gasket Thickness: 10 mm
Reactor & Operating Performance:
PTFE Liner & Construction:
Product Weight: 1.45 kg
Sterilization Parameters:
Product Weight: 2.25 kg
Packaging Information:
Operating Temperature: 200°C
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 5.65 kg
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 6.4 kg
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 6.5 kg
Thickness of Upper Gasket: 10 mm
Thickness of Lower Gasket: 10 mm
Sterilization Parameters:
Product Weight: 7.45 kg
Sealing Design: Leak Proof
Safety & Construction:
Safe Working Temperature: 220 °C
Recommended Heating and Cooling Rate: ≤5 °C/min
Wetted Material: Hastelloy
Venting System: Deflation / Vent Valve
Valve Material: 316L Stainless Steel
Temperature Monitoring: Temperature Probe
Vessel Wall Thickness: 5.5 mm
Vessel Material: 316L Stainless Steel
Vessel Inner Diameter: 27 mm
Vessel Height: 53 mm
Vessel Wall Thickness: 5.5 mm
Vessel Material: 316L Stainless Steel
Vessel Inner Diameter: 27 mm
Vessel Height: 64 mm
Vessel Wall Thickness: 5.5 mm
Vessel Material: 316L Stainless Steel
Vessel Inner Diameter: 27 mm
Vessel Height: 64 mm
